| Manufacturer | NXP USA Inc. |
|---|---|
| Series | M683xx |
| Packaging | Tray |
| Part Status | Obsolete |
| Core Processor | M68000 |
| Number of Cores/Bus Width | 1 Core, 8/16-Bit |
| Speed | 16MHz |
| RAM Controllers | DRAM |
| Graphics Acceleration | No |
| Voltage – I/O | 5.0V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 132-BPGA Exposed Pad |
| Supplier Device Package | 132-PGA (34.5×34.5) |
| Additional Interfaces | GCI, IDL, ISDN, NMSI, PCM, SCPI |
| Base Product Number | MC683 |
| Co-Processors/DSP | Communications; RISC CPM |
