| Mfr | Freescale Semiconductor |
|---|---|
| Series | 56F8xxx |
| Packaging | Tray |
| Part Status | Obsolete |
| DigiKey Programmable | Not Verified |
| Core Processor | 56800E |
| Core Size | 16-Bit |
| Speed | 40MHz |
| Peripherals | POR, PWM, WDT |
| Number of I/O | 76 |
| Program Memory Size | 512KB (256K x 16) |
| Program Memory Type | FLASH |
| RAM Size | 16K x 16 |
| Voltage – Supply (Vcc/Vdd) | 2.25V ~ 3.6V |
| Oscillator Type | External |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 160-MAPBGA (15×15) |
| Package / Case | 160-BGA |
| Base Product Number | MC56F81 |
| Data Converters | A/D 16x12b |
| Connectivity | EBI/EMI, SCI, SPI |
