| Mfr | NXP USA Inc. |
|---|---|
| Series | 56F8xx |
| Packaging | Tray |
| Part Status | Obsolete |
| DigiKey Programmable | Not Verified |
| Core Processor | 56800 |
| Core Size | 16-Bit |
| Speed | 80MHz |
| Peripherals | POR, PWM, WDT |
| Number of I/O | 32 |
| Program Memory Size | 120KB (60K x 16) |
| Program Memory Type | FLASH |
| RAM Size | 4K x 16 |
| Voltage – Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Oscillator Type | External |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 160-LQFP (24×24) |
| Package / Case | 160-LQFP |
| Base Product Number | DSP56F807 |
| Data Converters | A/D 16x12b |
| Connectivity | CANbus, EBI/EMI, SCI, SPI |
