Manufacturer's product number
Manufacturer
Description
Detailed description
Download
| Mfr | NXP USA Inc. |
|---|---|
| Series | 568xx |
| Packaging | Tray |
| Part Status | Obsolete |
| DigiKey Programmable | Not Verified |
| Core Processor | 56800E |
| Core Size | 16-Bit |
| Speed | 120MHz |
| Peripherals | POR, WDT |
| Number of I/O | 11 |
| Program Memory Size | 12KB (6K x 16) |
| Program Memory Type | SRAM |
| RAM Size | 4K x 16 |
| Voltage – Supply (Vcc/Vdd) | 1.8V ~ 3.3V |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 81-MAPBGA (8×8) |
| Package / Case | 81-LFBGA |
| Base Product Number | DSP568 |
| Connectivity | EBI/EMI, SCI, SPI, SSI |
